FlatbedCascade14,000 lb.

Cascade Series 6″ Flatbeds 14K

Cascade Series 6″ Flatbed 14K

STANDARD FEATURES

Coupler StyleAdjustable (5 position)Fender TypeTeardrop (Diamond Plate)
Ball Size2 5/16"Tire SizeST 235/80R16E
Saftey Chains3/8" w/Clevis LatchBolt Pattern8 on 6.5
Jack7K Drop LegTire TypeSteel Belted Radials (Nitrogen Filled)
Plug7 Way RVTire PSI80#
Tongue6" Channel (Full Wrap)Tire Weight Rating2540#
Main Frame6" ChannelLighting (Clearance)LED Bullet
X-members3" Channel (18" on Center)Lighting (Stop)Sealed LED (24 Diode)
Axles7000#Decking2x6 Doug Fir (Premium)
BrakeElectricPaint TypePolyurethane
Brake Size12" x 2"Paint ColorHigh Gloss Black or Charcoal Metallic
Ramps5' Ramps (Channel)WarrantyLifetime Structural (Limited)
D-Rings4 - 5/8"

ACCESSORIES & OPTIONS

Spare Mount (Welded)Spare Tire
Spare Mount (Removable)Pressure Treated Decking
Removable FendersRear Stabilizer Jacks

SPECIFICATIONS AND PRICING

ModelC6FB714TA5C6FB716TA5C6FB718TA5C6FB720TA5
Tongue Length49"49"49"49"
Deck Length170"194"218"242"
Deck Width83"83"83"83"
Overall Width102"102"102"102"
Overall Length222 1/4"246 1/4"270 1/4"294 1/4"
Fender Height7 3/4"7 3/4"7 3/4"7 3/4"
Deck Height22 1/2"22 1/2"22 1/2"22 1/2"
GVWR14,00014,00014,00014,000
Curb Weight *2,1562,2902,4312,559
Payload Capacity11,84411,71011,56911,441

* Weights shown are estimates for base models without options
